Introduction: The frequency converter is mainly composed of rectification (AC to DC), filtering, inversion (DC to AC), braking unit, driving unit, detection unit, microprocessor unit, etc. The frequency converter adjusts the voltage and frequency of the output power supply by disconnecting the internal IGBT, providing the required power supply voltage according to the actual needs of the motor, thereby achieving energy saving and speed regulation. In addition, the frequency converter also has many protection functions, such as overcurrent, overvoltage, overload protection, etc. With the continuous improvement of industrial automation, frequency converters have also been widely used.


Application scope: Variable frequency speed regulation for welding machines, constant pressure water supply, various fans, central air conditioning, and hydraulic pumps.


Application case:


Application circuit:
